Application Range

Five types of Clamp-on Ultrasonic Flowmeter

The clamp-on sensor is installed on the surface of the pipe, and different sensors are selected to adapt to the caliber DN15~DN6000

1.Handheld Clamp-on Ultrasonic Flowmeter

The handheld ultrasonic flowmeter is easy to carry and can be carried with you in a suitcase.

2.Wall mounted clamp on ultrasonic flow meter

Wall Mounted Clamp-on Ultrasonic Flowmeter can be installed on the wall, instrument box, distribution box, and the protection level of the host reaches IP67.

3.Modular clamp-on ultrasonic flowmeter

The flow meter is small in size, full of functions, and low in price. It is installed on a guide rail and is suitable for batch use and installation in an instrument box or power distribution cabinet.

4.Integrated clamp-on ultrasonic flowmeter

The flow meter and sensor are installed on the measuring pipeline, and the flowmeter's protection level is IP68

5.Explosion-proof clamping ultrasonic flowmeter

Mainly use isolation type explosion-proof, used in flammable and explosive occasions, explosion-proof grade DⅡBT5

Function

Measure instantaneous flow

Measure the cumulative flow

Measure the flow rate

Measure the energy

Two way measurement system, forward total amount, reverse total amount and difference total amount, can display positive and reverse flow.

Features:

♦ Adopt non-contact measurement method

♦ Wide measuring range

♦ There are no moving mechanical parts, and it is not affected by system pressure and harsh environment.

♦ Very wide application

♦ Large screen LCD display,small size, light weight

♦ Built in data recorder and rechargeable battery.

♦ Fault self diagnosis function, no data loss after power failure
