The STS ultrasonic water meter is a smart prepaid solution designed for modern water management systems. Combining high-precision ultrasonic measurement with secure STS encryption technology, it enables accurate billing, remote management, and reliable operation.
Deliver Condition:
Diameter：DN15-DN25
Accuracy Class：Class 2
Max Pressure：1.6 MPa
Pressure Loss：△p40
Temperature：-20~55℃
Protection：IP68
Power Supply:3.6V Lithium Battery
Communication:LoRa
Battery life:10 years
Display:LCD
Electromagnetic Class：E2
Optional modules available:NB-IoT/4G/LoRaWAN
Function:
Smart water networks
Utility companies
Industrial water monitoring
Remote metering projects
|
Diameter (mm) |
R |
Q4 (m³/h) |
Q3 (m³/h) |
Q2 (m³/h) |
Q1 (m³/h) |
Min. Reading m³ |
Max. Reading m³ |
|
DN15 |
250 |
3.125 |
2.5 |
0.05 |
0.03125 |
0.0001 |
99999 |
|
DN20 |
250 |
5 |
4 |
0.08 |
0.05 |
0.0001 |
99999 |
|
DN25 |
250 |
7.875 |
6.3 |
0.126 |
0.07875 |
0.0001 |
99999 |
