Single jet Smart LORAWAN water meters are widely used in municipalities for smart water management, helping to optimize water usage and enhance sustainability efforts. They are also suitable for residential buildings.
Function of Single jet smart LoRaWAN water meter
♦ Battery:6- 8 years.
♦ Magnet triggers reporting of data
♦ Metering data is stored once a day
♦ The LCD display screen displays accumulated flow.
♦ Mobile phone configuration parameters
♦ NFC settings and reading meter parameters
♦ Early warning system: battery undervoltage and abnormal metering alarm
Deliver condition:
1.Size:DN15-DN20
2.Body:Brass with valve/without valve
3.R:80/100/160
4.Type:digital
5.Max work pressure:PN16.
6.Protection class:IP65
7.Protocol:LoRaWAN
8.Frequency:433 MHz 470 MHz 868MHz 915MHz 923 MHz
9.Pressure loss:≤0.063Mpa,Water temperature:T30
10.Standards:ISO4064
11.Software: Free
12.Composition:single jet LoRaWAN water meter Base station, Serve Platform
Smart water management
Residential buildings
High-end communities
Villas
Schools
Apartments
Water affairs
Size | Specification mm | Nut thread | Joint thread | ||
L | W | H | |||
DN15 | 110 | 69 | 75 | G 3 / 4 B | R1 /2 |
